Video Link

This video demonstrates implementation of AWS Kinesis Producer and Consumer using Java + LocalStack setup.

---

Steps to follow for WebSocket API creation

1. Build API and give

   1. API name
   2. Route selection expression —> request.body.action

2. Add routes

   1. Add $connect route
   2. Add $disconnect route

3. Attach integrations

   1. $connect

      1. Type → HTTP
      2. Method → POST
      3. URL → <enter api-endpoint here>/connect

   2. $disconnect

      1. Type → HTTP
      2. Method → POST
      3. URL → <enter api-endpoint here>/disconnect

4. Add stages

   1. name → prod
5. Create and deploy

---

Edit $disconnect route

Open ‘Integration Request’

• Uncheck ‘Use HTTP Proxy integration'
• Click ‘Save’

• Edit ‘Request Templates’

  • Template Selection Expression → \$default → click ‘check’ button

---

Edit $connect route

Open Integration Request

• Uncheck ‘Use HTTP Proxy integration'
• Click ‘Save’

• Edit ‘Request Templates’

  • Template Selection Expression → \$default → click ‘check’ button

Add integration response

• Open integration response

  • Response Selection Expression will be ${integration.response.statuscode}

• Add Response

  • Response Key → $default → click ‘check’ button
  • Edit ‘Template Selection Expression’ → \$default → click ‘check’ button

---

Authorizers

Click ‘Create New Authorizer’

• Name → **lambda-authorizer**
• Lambda Function → lambda-authorizer (us-east-1)

• Identity Sources

  • Query String → token
• Click ‘Create’ → ‘Grant & Create’

Attach the authorizer to $connect route

• Open ‘Route Request’
• Click ‘Pencil icon’ of Authorization

• Select the configured Lambda Authorizer and save

  • If you don’t see the lambda → refresh the page once

---

Update $connect Route using AWS CLI

First gather some information

1. API ID

   • Note down API ID from URL of the API page of AWS Console

2. RouteId and IntegrationId

   1. Execute below command

      • aws apigatewayv2 get-routes --api-id bnzlep5vqk
   2. Note down RouteId and Target from response of below command, where RouteKey is $connect
   3. ‘Integration Id’ is the alphanumeric part after the slash in Target value. Eg: f3m2883 is the ‘Integration Id’ in the"Target": "integrations/f3m2883"

Now update the route as follows

aws apigatewayv2 update-route \
--api-id bnzlep5vqk \
--route-id ik7cvjt \
--request-parameters '
{
    "route.request.querystring.stocks":{"Required":true}
}'

Update $connect Integration using AWS CLI

aws apigatewayv2 update-integration \
--integration-id f3m2443 \
--api-id bnzlep5vqk \
--request-parameters 'integration.request.querystring.stocks'='route.request.querystring.stocks'

aws apigatewayv2 update-integration \
--integration-id f3m2443 \
--api-id bnzlep5vqk \
--request-parameters 'integration.request.querystring.connectionId'='context.connectionId'

aws apigatewayv2 update-integration \
--integration-id f3m2443 \
--api-id bnzlep5vqk \
--request-parameters 'integration.request.querystring.userId'='context.authorizer.userId'

aws apigatewayv2 update-integration \
--integration-id f3m2443 \
--api-id bnzlep5vqk \
--request-parameters 'integration.request.querystring.orgId'='context.authorizer.orgId'

You can confirm the updates by fetching the integration details as below

aws apigatewayv2 get-integration \
--integration-id f3m2443 \
--api-id bnzlep5vqk

---

---

Update $disconnect Integration using AWS CLI

First gather some information

1. API ID remains same from the previous step

2. RouteId and IntegrationId

   1. Execute below command

      • aws apigatewayv2 get-routes --api-id bnzlep5vqk
   2. Note down RouteId and Target from response of below command, where RouteKey is $disconnect
   3. ‘Integration Id’ is the alphanumeric part after the slash in Target value. Eg: f3m2883 is the ‘Integration Id’ in the"Target": "integrations/f3m2883"

Update $disconnect Integration using AWS CLI

aws apigatewayv2 update-integration \
--integration-id 478fpcf \
--api-id bnzlep5vqk \
--request-parameters 'integration.request.querystring.connectionId'='context.connectionId'

---

Deploy & Test

Refresh the console page once and DEPLOY 🚀

To test use below command (make sure the tool is installed)

wscat -c "wss://ojp5zwbo3k.execute-api.ap-southeast-1.amazonaws.com/prod?stocks=aapl,goog"

---

Configure API

After deployment, the API endpoint should be configured in the backend project as an environment variable like below

WSAPIENDPOINT	https://bnzlep5vqk.execute-api.ap-southeast-1.amazonaws.com/prod

---
